| T/S SPECS | SAv2 15″ D2 | SAv2 15″ D4 |
| RE (Ohms) | 3.89 | 5.83 |
| FS (Hz) | 36.8387 | 37.4160 |
| VAS (L) | 51.9387 | 45.3391 |
| Qes | 0.5847 | 0.6963 |
| Qms | 5.1005 | 5.7094 |
| Qts | 0.5245 | 0.6206 |
| Le (mH) | 3.6326 | 4.7903 |
| BL (NA) | 24.4656 | 29.1578 |
| Mms (Grams) | 388.9706 | 431.9464 |
| Cms (uM/N) | 47.9860 | 41.8886 |
| Sens (dB @ 1w/1m) | 88.22 | 87.08 |
| ENCLOSURE SPECIFICATIONS |
| Sealed Enclosure | 2.0 cu ft |
| Ported Enclosure | 3.0 cu ft |
| Recommended Tuning | 35Hz |
| Recommended Port Area | 44 sq in |
