| T/S SPECS | SAv2 18″ D2 | SAv2 18″ D4 |
| RE (Ohms) | 3.97 | 6.06 |
| FS (Hz) | 29.051 | 31.868 |
| VAS (L) | 114.234 | 106.964 |
| Qes | 0.424 | 0.458 |
| Qms | 3.052 | 2.853 |
| Qts | 0.372 | 0.395 |
| Le (mH) | 3.6326 | 4.7903 |
| BL (NA) | 32.523 | 38.159 |
| Mms (Grams) | 619.174 | 549.519 |
| Cms (uM/N) | 48.474 | 45.389 |
| Sens (dB @ 1w/1m) | 90.1 | 90.7 |
| ENCLOSURE SPECIFICATIONS |
| Sealed Enclosure | 3.5 cu ft |
| Ported Enclosure | 4.5 cu ft |
| Recommended Tuning | 35Hz |
| Recommended Port Area | 66 sq in |
