  • Description

2 Channel Class D Amplifier

    SPECIFICATIONS

  • Power RMS 1Ω @ 14.4V: 2 x 125W
  • Power RMS 2Ω @ 14.4V: 2 x 69W
  • Power RMS 4Ω @ 14.4V: 2 x 38W
  • Bridge Power 2Ω @ 14.4V: 1 x 250W
  • Bridge Power 4Ω @ 14.4V: 1 x 138W
  • Bridge Power 8Ω @ 14.4V: 1 x 76W
  • THD+N @ Nominal Power: <1%
  • Frequency Response: 5Hz ~ 20kHz
  • Dimensions: 4-5/8" W x 4-1/2" L x 1-7/8" H



  • SNR: 99dB
  • Input Sensitivity: 0.5V to 6V
  • Damping Factor: 100
  • Operating Voltage: 9V to 16V
  • High Pass Filter: 45Hz to 850Hz
  • Low Pass Filter: 45Hz to 850Hz
  • Total Efficiency: 81%
  • Max Current Draw (A): 25
  • Music Current Draw (A): 13
