NS9005
Triton
Buy Now
ex Shipping
    Delivery time:5-7 Days
Add to cart
  • Description



5 Channel Class D Amplifier

      Specifications

    • Power RMS 2Ω @ 14.4V: 4 x 100W + 1 x 350W
    • Power RMS 4Ω @ 14.4V: 4 x 60W + 1 x 200W
    • Bridge Power 4Ω @ 14.4V: 2 x 200W + 1 x 500W @1Ω
      2 x 200W + 1 x 350W @ 2Ω
    • THD+N @ Nominal Power: <1%
    • Frequency Response (-3db): 10Hz ~ 20kHz
    • SNR: >80dB
  • Input Sensitivity: 00mV - 6V Low Level
    0.8V-24V High Level
  • High Pass Filter: 50Hz-250Hz
  • Low Pass Filter: 50Hz-250Hz
  • Dimensions: 11.77” x 6.22” x 2.03”
  • Recommended Amp Kit: 4GKIT
