  • Description

Mono Channel Class D Amplifier

    SPECIFICATIONS

  • Power RMS 1Ω @ 14.4V: 1 x 1200W
  • Power RMS 2Ω @ 14.4V: 1 x 660W
  • Power RMS 4Ω @ 14.4V: 1 x 363W
  • THD+N @ Nominal Power: 0.1%
  • Frequency Response: 10Hz ~ 30kHz
  • SNR: 99dB
  • Input Sensitivity: 0.5V to 8V
  • Dimensions: 7-7/8" W x 7-1/4" L x 2-1/8" H



  • Damping Factor: >1000
  • Operating Voltage: 9V to 16V
  • High Pass Filter: 5Hz to 80Hz
  • Low Pass Filter: 50Hz to 500Hz
  • Total Efficiency: 75%
  • Max Current Draw (A): 127
  • Music Current Draw (A): 63
