HDPD90
ex Shipping
    Delivery time:5-7 days
  • Description
  • More

Alpine Status 14ch Hi-Res DSP Amplifier

• 50 watts x 8 channel + 80 watts x 4 channel @ 4 ohms
• 50 watts x 8 channel + 160 watts x 2 channel bridged @ 4 ohms
• Total RMS Power: 720 watts
• Class D 4 ohms Stable 12-Channel Digital Sound Processor Amplifier

  • Alpine Status Series Class D 4 ohms Stable 12-Channel Amplifier
  • RMS Power Rating:
    • 4 ohms: 50 watts x 8 channel + 80 watts x 4 channel
    • 4 ohms: 50 watts x 8 channel
    • Bridged: 160 watts x 2 channel @ 4 ohms
  • Total power output: 720 watts
  • Pulse Width Modulated MOSFET power supply
  • Hi-Res Audio DSP Amplifier
  • Built-in 12-channel amplifier
  • MUSES 8820 operational amplifier
  • Highly flexible system configuration
  • Matrix input summing
  • High-Class XO (1/1.000) Crystal Oscillator Clock Generator
  • 31-Band / Channel Parametric / Graphic Equalizer
  • Digital Time Correction
  • External Bluetooth dongle included
  • High-performance PC software
  • LED Power/Protect Light
  • Wired remote bass level control available RUX-C810 (sold separately)
  • 3-way protection circuitry (thermal, overload, and speaker short protection)
  • Input sensitivity:
    • High level: 26 - 8 volts
  • Frequency Response: 20 - 40000 Hz
  • Total Harmonic Distortion (THD): .001%
  • Signal to Noise Ratio: >110 dB
  • Fuse Rating: 60A
  • 4 AWG gauge power and ground wiring is recommended for installation.
  • Dimensions: 11" W x 10-1/8" L x 2-5/16" H
