| T/S SPECS | SAv2 10″ D2 | SAv2 10″ D4 |
| RE (Ohms) | 3.90 | 6.82 |
| FS (Hz) | 37.0810 | 36.1409 |
| VAS (L) | 10.3683 | 12.3547 |
| Qes | 0.3598 | 0.3744 |
| Qms | 3.7041 | 3.5051 |
| Qts | 0.3280 | 0.3383 |
| Le (mH) | 3.5178 | 4.4560 |
| BL (NA) | 28.3634 | 31.5270 |
| Mms (Grams) | 318.8226 | 281.6632 |
| Cms (uM/N) | 57.7815 | 68.8513 |
| Sens (dB @ 1w/1m) | 83.42 | 83.67 |
| ENCLOSURE SPECIFICATIONS |
| Sealed Enclosure | 0.5 cu ft |
| Ported Enclosure | 1.0 cu ft |
| Recommended Tuning | 35Hz |
| Recommended Port Area | 15 sq in |
