Alliance 4x75 Class A / B Amplifier
VL1200.4
Features
- Small Footprint Class D Amplifier
- Utilizes Class D Technology
- Full Range Class D
- Low Level Inputs
- 80% more efficient than traditional Class A/B amplifiers
Specs
- Peak Power: 1200W
- Power RMS 2Ω @ 14.4V: 4 x 150 Watts
- Power RMS 4Ω @ 14.4V: 4 x 75 Watts
- THD+N @ Nominal Power: 4×75 Watts 4Ω
- Frequency Response: 10Hz ~ 30kHz
- SNR: 93dB
- Input Sensitivity: 0.2V to 6V
- Damping Factor: 100
- Operating Voltage: 9V to 16V
- High Pass Filter: 50Hz to 250Hz
- Low Pass Filter: 50Hz to 250Hz
- Total Efficiency: 70%
- Max Current Draw (A): 53
- Music Current Draw (A): 28
Dimensions
- Size (W x L x H): 5.8” x 9.8” x 1.9”
What’s in the box
- Alliance 4-Channel 1,200W Class D Amplifier
